Technical Parameters

Test Current Range

S15C2000

0.5 kA - 20 kA (± 10%)

S15C3000

0.5 kA - 30 kA (± 10%)

S15C4000

0.5 kA - 40 kA (± 10%)

Charging Voltage

≤15 kV

Current Waveform

Wavefront time: 8 μs ± 10%
Half peak time: 20 μs ± 10%
The wavefront time is defined as 1.25 * (10% -90%)
The half peak time is defined as 1.18 * (50% -50%)

Polarity

Positive, negative, first positive and then negative

Source Output Impedance

S15C2000

≤0.75 Ω(20 kA)

S15C3000

≤0.5 Ω(30 kA)

S15C4000

≤0.4 Ω(40 kA)

Repetition Rate (single pulse time)

11 s - 99 s (the shortest time depends on the test current value)

Number of Rials

1 - 999

Trigger Method

Manual, automatic, external triggering

General Parameters

Display

5.7 inch TFT touch screen

Working Power Supply Range

AC 220V， ±10%，50/60 Hz±5%(Domestic default AC 220 V 50 Hz)

Fuse

10A

Maximum Power Consumption

1500 W

Communication Methods

Ethernet LAN

External Control Methods

25 pin parallel thread

External Trigger Input

BNC, 5 V TTL

Operation Control Input

BNC, 5 V TTL

Instrument Grounding Connection Method

Using a flat grounding wire

Chassis Size(All S15C series are consistent)

22U cabinet (600mm * 800mm * 1250mm)

Instrument Weight

S15C2000

Approximately 142 kg

S15C3000

Approximately 152 kg

S15C4000

Approximately 162 kg

Environmental Scope

15℃ -35℃

Pressure Range

86 kPa - 106 kPa

Humidity Range

45% - 75%
