Technical Parameters

As per Standards

IEC/EN 61000-4-8, GB/T 17626.8

Magnetic field strength

MFS 400

1 A/m – 100 A/m (continuous), 100 A/m – 400 A/m(1 s – 10 s, short-term)

(with TCXS 111 single- turn1,000*1,000 mm square coil);

MFS 1200

1 A/m – 300 A/m (continuous),

300 A/m – 1,200 A/m (1 s - 10 s, short-term)

(with TCXS 113 three-turn1,000*1,000 mm square coil);

Output accuracy

less than 1dB;

(Minimal magnetic field strength such as 1A/m shall be calibrated manually before test）

Current waveform

50 Hz/60 Hz sinusoid

Current distortion

<5%

Pulse interval

1 s - 9,999s

Test duration

1 s - 28,800s

Triggering mode

Automatic, manual or external signal triggering

Coil size

1,000*1,000mm or other

Coil shape

Square/circular

General Parameter

Display screen

5.7 inch TFT touch screen

Operating power supply

110V/220V, ±10%, 50/60Hz

(AC 220V 50Hz by default)

Fuse

6A

Max. Power consumption

100W

Memory space

Infinite（PC）

Communication method

Ethernet LAN, RJ45

Output method

Standard 1m coaxial cable

Dimension

19 inch/6U/4U

Weight

Approx. 35Kg+68Kg

Operating temperature

15–35℃

Operating humidity

45%–75%

Operating air pressure

86kPa–106kPa
