Technical Parameters |
||
|
Test Interval |
5 s – 99 min 99 s |
|
|
Test Duration |
99 min 99 s |
|
|
No. of Tests |
1 – 999 |
|
|
Triggering Method |
Automatic / manual |
|
|
Main Operating Power |
Single-phase AC 220 V (±5%), ≥150 kVA, 50 Hz / 60 Hz (± 5%) |
|
|
Auxiliary Operating Power |
Single-phase, AC 220 V (±10%), ≤10 A |
|
|
Dimension |
1,400 x 750 x 1,700 mm |
|
|
Weight |
1,100 kg |
|
|
Output Voltage |
Test Mode |
Output Current (±10%) |
|
AC 100 V – 300 V (±10%) |
Contact mode < 20 min |
9 A – 27 A; 22 A – 66 A |
|
AC 400 V (±10%) |
Inductance mode < 1 min |
0.5 A; 1 A; |
|
Contact mode < 20 min |
5 A; 15 A; 30 A; 60 A; 120 A; 350 A; |
|
|
AC 600 V (±10%) |
Inductance mode < 1 min |
0.5 A; 1 A; 7 A; 40 A; 60 A; |
|
Contact mode < 20 min |
2.2 A; |
|
|
AC 1,000 V (±10%) |
Contact mode < 20 min |
0.5 A; 15 A; 30 A; 60 A; 120 A; |
