HOME>Products>EMC General Test Equipments>Common-Mode Conducted Immunity Simulator >Balanced / Unbalanced Impedance Converter Balun 50/10

Balanced / Unbalanced Impedance Converter Balun 50/10

Model：Balun 50/10

Profile

Balanced / Unbalanced impedance converter Balun 50/10 is designed according to IEC 61000-4-19:2014, capable of converting balanced signal to unbalanced signal with the impedance from 10Ω to 50Ω at the same time: PDF Consultation

Online customized according to your needs>>

Share

Feature
Standard
Parameter
Fitting
Services
Video

Balun 50/10 is designed according to IEC 61000-4-19:2014, capable of converting balanced signal to unbalanced signal with the impedance from 10Ω to 50Ω at the same time. It is widely used in tests on CDN characteristics (conduction sensitivity / immunity tests) and tests on antenna characteristics.

IEC 61000-4-19:2014

Technical Parameters
Frequency	1 kHz – 1 MHz
Ratio of Conversion	1:2.25
Impedance Ratio	1:5
Insertion Loss	0 dB
Max Unsaturated Voltage	30 V
Weight	0.6 kg
