Technical Parameters |
|||
|
Model No. |
SND-10NF-U |
SND-10NF-I |
SND-10NF-S |
|
Rated Voltage |
42.4 V ~700 V AC |
2 V ~60V DC |
|
|
Rated Current |
16 A；30 A；100 A |
16 A；30 A；100 A |
2 A |
|
Residual Voltage Ratio（EMS is Applied to） |
100：1 |
100：1 |
100：1 |
|
Insertion Loss |
30 MHz~230 MHz >20 db 230 MHz~1G Hz >20 db |
300 kHz~30 MHz >20 db 30 MHz~230 MHz >20 db 230 MHz~1G Hz >20 db |
300 kHz~30 MHz >20 db 30 MHz~230 MHz >20 db 230 MHz~1G Hz >20 db |
|
Isolation Voltage |
AC 1500 V DC 1500 V |
AC 1500 V DC 1500 V |
AC 1500 V DC 1500 V |
|
Leakage Current |
<10 mA |
<10 mA |
<10 mA |
|
Ambient Temperature |
10℃ ~40℃ |
10℃ ~40℃ |
|
|
Relative Humidity |
5%~85%， 85% @40℃ |
5%~85%， 85% @40℃ |
5%~85%， 85% @40℃ |
|
Storage Environment |
-10℃ ~70℃ ，90% RH |
-10℃ ~70℃ ，90% RH |
-10℃ ~70℃ ，90% RH |
|
Altitude |
60 m - 3000 m |
60 m - 3000 m |
60 m - 3000 m |
|
280 mm (L) x 102 mm (W) x 350 mm (H) |
280 mm (L) x 102 mm (W) x 350 mm (H) |
120 mm (L) x 103 mm (W) x 234 mm (H) |
|
|
Standard Accessories |
|
SND Decoupling Network Test Cables Grounded Cables Factory Inspection Report Quality Guaranteed Manual Operating Instruction |
