TPS-CS115 Fast square wave pulse generator is a generator specially designed to meet the standards GJB 151A-97 CS115, GJB 151B-2013 CS115 and MIL-STD-461E/F/G CS115. The generator produces fast square-wave pulses for conducting sensitivity tests on interconnect cables and power cables for all aircraft, space and ground systems. The equipment is also suitable for equipment and sub-system testing on surface ships and submarines when specified by the ordering party.
Features:
> 5.7 Inch color touch screen front panel operation
> Meet the test requirements of CS115 standard in GJB 151A-97 and GJB 151B-2013
> Meets the CS115 standard test requirements in MIL-STD-461 E/F/G
> Ethernet RJ45 port for remote control by PC
|
Technical Parameters |
||
|
Maximum test current |
≥5 A（loop impedance 100 Ω） |
|
|
Repetition frequency |
1-50 Hz |
|
|
Rise time（10%-90%） |
≤2 ns |
|
|
Fall time（90%-10%） |
≤2 ns |
|
|
Pulse width（90%-90%） |
≥30 ns |
|
|
Output impedance |
50 Ω |
|
|
Output interface |
Type N |
|
|
Common Parameter |
||
|
Working power supply |
AC 220 V，土10%，50-60 Hz (AC 220 V for China mainland) |
|
|
Ambient humidity |
45%-75% RH（no condensing） |
|
|
Relative humidity |
15-35 ℃ |
|
|
Dimensions |
19 Inch 4U |
|
|
Weight |
Approx. 18Kg |
|
|
Standard Accessories |
|
|
Main machine, manual, test report, warranty, test wire, power cord, grounding wire |
|
|
Optional Accessories
|
|
|
Current injection clamp and calibration clamp (required, two options available) |
|
|
Option 1. Current injection clamp BCIP-200 and calibration clamp BCICF-200
|
Frequency range :10 kHz ~ 200 MHz Inner diameter φ40 mm |
|
Option 2. Current injection clamp BCIP-400 and calibration clamp BCICF-400  |
Frequency range :10 kHz ~ 200 MHz Inner diameter φ40 mm |
|
Note: This generator only matches BCIP-200 and BCICF-200 or BCIP-400 and BCICF-400 and FCC related products. |
|
|
1.High-Voltage Coaxial Load HCL 50N
|
50 Ω 5 W DC-100 MHz |
|
2. Attenuator TFB 100  |
40±1.5 dB 5 W DC-400 MHz |
|
3. Broadband current monitoring clamp TWCM-200  |
Frequency range 10 kHz-200 MHz Inner diameter φ40 mm |
|
4. LISN J50
|
Max. continuous current 50 A Impedance 50 uH+5 Ω‖5 0Ω |
|
5. LISN J200
|
Maximum
continuous current 200 A |
